Bobcat E50z

Bobcat E50z

Mini Excavator For Rent Selangor
Mini Excavator For Sale Selangor

The new Bobcat® E50z is a new generation model in the 5 tonne compact excavator class, offering the benefits of Zero House Swing design. The E50z model is an easy-to-use, robust machine, introducing the next level of operator comfort and features required by demanding owner-operators. Increased weight has been optimized to maximize stability, which enables us to offer the long arm as standard. Thanks to the Bobcat platform design approach, the E50z benefits from the majority of features found on mainstream models.

Product Description

Bobcat E50z Specifications
Key Specifications
Horsepower 48.9 hp
Operating Weight 4819 kg
Dig Depth 3553 mm
Model
Series R
Tail Swing Type Minimal
- Tail Swing Type 55 mm
Weight 4819 kg
Dig Depth 3553 mm
Reach @ Ground Level 5922 mm
Dump Height Clearance 3953 mm
Width 1960 mm
Ground Pressure 34.8 kPa
- Standard Track Width 350 mm
Performance
Arm Breakout Force 22171 N
Bucket Breakout Force 37744 N
Rated Lift Capacity -
(Over blade, ground level, 10 ft. (3 m) reach) 2513 kg
(Over side, ground level, 10 ft. (3 m) reach) 705 kg
Travel Speed: Low/High 2.9/5.3 km/hr
Long Arm Option Performance
Tail Swing Type/Overhang -
Weight (with Long Arm & Counterweight) -
Dig Depth -
Reach @ Ground Level -
Dump Height Clearance -
Engine
Horsepower 48.9/36.5 hp/kw
Engine Type Interim Type 4
Fuel Tank Capacity 72 L
Hydraulics
Piston Pump Yes
Load-Sensing Pump Yes
Machine Features & Options
Angle Blade -
Auto-Idle Throttle Standard
Auto-Shift Travel System Standard
Automatic Slew Brake Standard
Blade Float Standard
Cab with Heat Optional
Cab with Heat and A/C Optional
Control Pattern Selector Standard
Deluxe Cloth Seat Optional
Fingertip Boom Swing Control Standard
Fold-Down TOPS -
Keyless/Password Start System Optional
Retractable Undercarriage -
Steel Tracks Optional
Features for Attachments
Auxiliary Hydraulics with Quick Couplers Standard
Auxiliary Hydraulic Flow 75.7 L/min
Auxiliary Hydraulic Pressure 210 bar
Fingertip Auxiliary Control Standard
Secondary Auxiliary Hydraulics Optional
Selectable Auxiliary Flow Standard
